Beschreibung
x3U OpenVPX Backplane mit zehn Steckplätzen nach VITA 65, Backplane profile BKP3-CEN10-15.2.5-n, payload slot profile SLT3-PAY-1F2F2U-14.2.2, switch slot profile SLT3-SWH-2F24U-14.2.3 and SLT3-SWH-8F-14.4.2, Stromverbindungen mit M3/M4 Powerbolzen
Produktmerkmale
x- BKP3-CEN10-15.2.5-n Backplaneprofil entspricht VITA 65 specification
- 1 x Fat Pipe Data Plane (Fat Pipe = 4 x Lanes), Star
- 2 x Ultra Thin Pipe Control Plane (Ultra Thin Pipe = 1 x Lane), Dual-Star
- 2 x Fat Pipe Data Plane (Fat Pipe = 4 x Lanes), Daisy Chain
- Slot 1-4, 7-10: SLT3-PAY-1F2F2U-14.2.2
- Slot 6: SLT3-SWH-8F-14.4.2 (Data Plane Switch)
- Slot 6: SLT3-SWH-8F-14.4.2 (Data Plane Switch)
Produktinformation
xArtikel-/Teilenummer65c310-1525-40
Artikelbeschreibung3 HE OpenVPX Backplane, 10 Slots, Profil BKP3-CEN10-15.2.5-n
Schlüssel10
